OMG-LP-15CF Servo

Item No. OMG-LP-15CF

Operating voltage:4.8-8.4V

Operating speed:

6.0V-0.065sec/60°

7.4V-0.058sec/60°

Stall torque:

6.0V-15kgf.cm(208oz-in)

7.4V-16.5kgf.cm(229oz-in)

Gear Material:Stainless steel

Horn gear spline:25T Φ5.9

Size:41x20.5x29mm

Case Material:Top & middle cover in full metal ,bottom cover in plastic

Weight:60g

Bearing:2BB

Motor type:Coreless

Operating Temperature:-15℃~+70℃

Operating travel :≈180±10°

Neutral position :1520μsec

Frequency:1520uS

Refresh Rate:333Hz

Pules width range :500-2500μsec

Dead band width:2μsec

Connector wire length:180mm

Waterproof level:Dust & Water Splash Resistacne

Programmable:Yes
